Hikvision DS-2CE76D0T-LPFS

Hikvision DS-2CE76D0T-LPFS: ClearView Dome Camera

Get peace of mind with the Hikvision ClearView Dome Camera! This compact camera delivers crisp 1080p high-definition video, ensuring you don’t miss a thing, day or night. With its built-in microphone, you’ll not only see, but also hear what’s happening. Designed for easy installation, it’s perfect for keeping an eye on your home or small business, offering reliable surveillance with a discreet presence. Enjoy clear footage and enhanced security, all in one smart package.

Product Specifications: Hikvision DS-2CE76D0T-LPFS

The Hikvision DS-2CE76D0T-LPFS is a versatile 2 MP (megapixel) fixed mini dome camera, part of Hikvision’s Turbo HD product line, offering high-definition video over coaxial cable. Its image sensor is a 2 MP CMOS, capable of delivering a maximum resolution of 1920 (H) $\times$ 1080 (V) at 25 frames per second (fps) or 30 fps, ensuring smooth and detailed footage.

This camera supports 4-in-1 video output, meaning it’s compatible with TVI, AHD, CVI, and CVBS signal formats, providing broad compatibility with various DVR systems. The lens type is a fixed focal lens, available in common focal lengths like 2.8 mm or 3.6 mm, offering different fields of view. A 2.8 mm lens typically provides a wider viewing angle, suitable for general surveillance, while a 3.6 mm lens offers a slightly narrower, more focused view.

For low-light conditions, the camera is equipped with an IR cut filter with auto switch and Smart IR technology, providing clear black and white images up to a range of 20 meters (65 feet). Smart IR automatically adjusts the intensity of the infrared LEDs to prevent overexposure of objects closer to the camera. It has a minimum illumination of 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR. The camera operates on a 12 VDC $\pm$ 25% power supply, with a maximum power consumption of 2.2 W.

Physically, the DS-2CE76D0T-LPFS is designed with an ingress protection rating of IP20 (not weatherproof) and has a plastic housing, making it suitable for indoor environments. Its compact dome design allows for discreet installation. The integrated high-quality audio over coaxial cable (AoC) feature simplifies installation by transmitting both video and audio signals through a single coaxial cable to compatible Hikvision AoC DVRs, eliminating the need for separate audio cabling.
